Attitude is everything.Details decide the success or failure!
8 Years
| Ask Lasest Price | |
| Brand Name : | JD |
| Model Number : | JD-2C |
| Certification : | ISO 9001:2008 |
| Price : | USD 2000-USD 5000/Set |
| Payment Terms : | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 30 Sets/Month |
| Delivery Time : | 20-30 days after received your advanced payment |
Supply Automatic Nail Making Machine For Building Nails
With High Performance and Low Noise
1.The nail making machine is used for producing various normal
nails and special nails.
2.Available Raw Material for nail making machine:
Normal wire, new metal wire, waste rebar, scrap steel bar,
hard-drawn wire, waste electrode, and other kind
of waste steel.
3.Process of nail making:
Wire-Rod → Wires-Drawing → Nail-Making → Polishing → Packing →
Delivery
4.Data of nail making machine:
| Item | Model | Length of nail | Diameter of nail | Capacity (pieces/m) | Power |
| Nail making machine | Z94-1C | 9.0-25mm | 0.9-1.6mm | 450 | 1.5kw |
| Z94-2C | 16-50mm | 1.2-2.8mm | 300 | 2.2kw | |
| Z94-3C | 30-75mm | 1.8-3.1mm | 280 | 3kw | |
| Z94-4C | 50-100mm | 2.8-4.5mm | 260 | 4kw | |
| Z94-5.5C | 80-150mm | 3.7-5.5mm | 200 | 5.5kw |
| Type : Z94-2.8A(50A) | Type : Z94-3A(70A) | Type : Z94-4A(100A) |
| Max nail diameter : 2.8mm Min nail diameter: 1.2mm | Max nail diameter : 3.1mm Min nail diameter: 1.8mm | Max nail diameter : 4.5mm Min nail diameter: 2.8mm |
| Max nail length : 50mm Min nail length: 16mm | Max nail length : 70mm Min nail length: 30mm | Max nail length : 100mm Min nail length: 50mm |
| Output : 350pc/min | Output : 320pc/min | Output : 260pc/min |
| Power: 2.2kw | Power: 3kw | Power: 4kw |
| Weight: 1000kg | Weight: 1500kg | Weight: 2000kg |
5.Machine feature:
(1)This nail making machine adopts plunger type structure so as to ensure the features such as high speed, low noise and less impact;
(2) Especially,our nail making machine can make the high quality of oil rivet nail and other shaped nails used for high speed welding nailer and nail gun;
(3)It has the features of advanced design, compact conformation, and good type. Easy and safe to operate.
6.Our Advantage
1.6 types of fully automatic nail making machines in our factory
2.all machines are high speed and low consumption with advanced technology
3.easy and safe to operate
4.supply auxiliary equipment
5.each machine will be equipped with one set mold for free
6.size can be made according to customer's request
Machine Package
Company Information
Long history
We have 15 years manufacturer history, companying with good reputation, since our factory set up in 2003.
Supply ability:
We specialize in design machines according customers' requirements. 300 sets of machines can be supplied/month.
Equipment working site:
You are welcomed to visit our factory, the machines can be operated on site, and you will master the usage of machines nearby.
Successful experience / Markets:
Be up to the international level. Our lines and related complete equipment have been exported to India, Indonesia, Morocco, South Africa, Algeria,Mexcio,bangladesh etc.
Our Services
Why let you choose us
1.Production experience:Absorbed ,Professional for 15years
2.Each link strict control the quality
3.Our goals are not do the lowest price to do the best quality
4. Life provides you with technical guidance
5. The long-term supply all kinds of spare parts, make sure that you use perennial
6. To offer our customers workshop design
7. Choose a professional supplier will bring you more convenient
|
